(currently work-in-progress)

If OdysseusNet is activated, the node has the possibility to distribute own queries to other remote OdysseusNodes. For this, the user has to specify that he wish to distribute:


This statement in Odysseus Script indicates that the queries which follows should be distributed in the network.

If you want to run several nodes on one machine, ensure that you set the configuration net.querydistribute.randomport=true. Otherwise, port conflicts may occur.

A better way would be to use docker-compose.

General process of query distribution

Query distribution in OdysseusNet is divided in three core phases: Partition, Modification and Allocation. Due to implementation reasons, two additional phases were integrated: Preprocess before Partition and Postprocess after Allocation. The picture below shows the three phases mentioned earlier (and the transmission phase).

At the beginning, Odysseus translates the query in a logical graph. This logical graph is preprocessed and then partitioned. The result of the Partition phase is a collection of query parts, which are individually modified in the Modification phase. However, the Modification-phase is optional an can be omitted. After that, the Allocation phase decides, which query part should be executed on which OdysseusNode. Finally, the query parts are transmitted to the selected nodes. Preprocess, Partition, Modification, Allocation and Postprocess provide multiple strategies the user can select from (individually for each query, if needed). Additionally, some strategies can be parameterised . The user has to use specific OdysseusScript keywords. One example for query distribution is as follows:

/// Indication that we want to distribute queries

#NODE_PREPROCESS SOURCE					/// Select Source strategy for pre-processing
#NODE_PARTITION OPERATORCLOUD			/// Select OperatorCloud strategy for Partition phase
#NODE_MODIFICATION REPLICATION 2		/// Select Replication strategy for Modification phase (with replication degree 2)
#NODE_ALLOCATION USER					/// Select User-strategy for Allocation phase
#NODE_POSTPROCESSOR LOCALSOURCES		/// Select multiple strategies for post-processing

/// "Typical" query definition here
#METADATA TimeInterval

The strategies are explained in the next sections. Partition and Allocation allow only one selected strategy. The other phases can be used multiple times per query. If the user had not specified strategies for some phases, OdysseusNet will use specific strategies as default (configurable):

PhaseDefault strategy

The Transmission phase cannot be altered.


Strategy nameDescription
sourceStreamAOs are replaced with their logical operators.


Strategy nameDescription
querycloudThe entire query is one query part (no partitioning).
operatorcloudEach logical operator is its own query part (max. partitioning)


Strategy nameDescription
replication <degree>Query parts are replicated (with replicationdegree degree), executed multiple times. See Replication.


Strategy nameDescription

All query parts are assigned to the specified OdysseusNode.

querycountQuery parts are assigned to nodes with the least count of queries.
roundrobinQuery parts are assigned in order.
userQuery parts are assigned to user-specified nodes. For this, each logical operator has a DESTINATION-Parameter in PQL. Two operators which have the same DESTINATION-value are assigned to the same node.


Strategy nameDescription
localsinkLogical sink operators are staying local (on the distributing node) overriding allocation. Useful if the user wants to have the last operator to check the data stream results.
localsourceLogical source operators are staying local (on the distribution node) overriding allocation. Useful if the user do not want to share its source operators to other nodes.
mergeTwo adjacent query parts which are assigned to the same node are merged to omit unneeded network-transmission operators.

Post processor to insert a sender for each {@link ReplicationMergeAO}. The sender will be inserted for the output port 1 that is not used normally. All discarded replicates are sent to port 1. The sender writes the data in a CSV file (one file per merger). The only argument for this post processor is the path to the CSV files. The names of the files are determined by the {@link ReplicationMergeAO} (name and hashCode).

Used sender settings:
- transport handler "file"
- data hgandler "tuple"
- wrapper "GenericPush"
- protocol handler "csv"
- "createDir" "true"
- "filename", path_from_user + "/" + merger.getName() + merger.hashCode() + ".csv"
- "append", "true"


Inserts a CalcLatencyAO before every real sink. Note that the ILatency metadata will be added to the sources automatically. This postprocessor needs the feature "Calculation Postprocessor Feature".

CalcDatarateInserts a DatarateAO after every source. Note that the IDatarate metadata will be added to the sources automatically. This postprocessor needs the feature "Calculation Postprocessor Feature".


A simple way to distribute whole queries (inklusing Odysseus Script parts) to other nodes can be done with the #REMOTEQUERY command:

#REMOTEQUERY (name=worker_1)
timer = TIMER({PERIOD = 1000, SOURCE = 'source'})
map = MAP({EXPRESSIONS = ['toString("marco")'], KEEPINPUT = true}, timer)
#REMOTEQUERY (name=worker_2)
timer = TIMER({PERIOD = 1000, SOURCE = 'source'})
map = MAP({EXPRESSIONS = ['toString("marco")'], KEEPINPUT = true}, timer)

Here, anything between two #REMOTEQUERY commands (or the end of the document) are copied and send as whole to the node to be processed there. Remark: This this different than "direct" from above as the query is not translated locally. By this, you could have e.g. multiple master nodes that will get the whole queries from another (super master) node.
